Product Name : New design of folding roof for 40FT open top
transport storage container
Open top container is also called open top container. This kind of
container has no rigid top, but has a canopy made of canvas,
plastic cloth or plastic coated cloth supported by a folding top
beam. When shipping, the top of the container is covered with
waterproof cloth. Its watertight requirement is the same as that of
a dry container, and goods can be loaded and unloaded from the top
of the container by a crane. It is suitable for loading large
objects and heavy objects to be lifted, such as glass plate, etc.
Application:
Can be use as storage,transport
20 40FT 0T DETAILS
| Dimensions--External | 20' Open Top | 40' Open Top |
| Length: | 6,058 mm | 12,192 mm |
| Width: | 2,438 mm | 2,438 mm |
| Height: | 2,591 mm | 2,591 mm |
| | |
| Dimensions--Internal | | |
| Length: | 5,902 mm | 12,036 mm |
| Width: | 2,350 mm | 2,350 mm |
| Height: | 2,348 mm | 2,348 mm |
| | |
| Dimensions--Door and Roof Openings | | |
| Minimum Door Opening Width: | 2,340 mm | 2,340 mm |
| Minimum Door Opening Height: | 2,280 mm | 2,280 mm |
| | |
| Minimum Roof Opening: | | |
| Width Between Top Rails | 2,252 mm | 2,232 mm |
| Length Between Top Headers | 5,674 mm | 11,798 mm |
| Length Between Troughs | 5,378 mm | 11,512 mm |
| | |
| Weight & Payload | | |
| Tare Weight (Design Estimate): | 2,300 kg | 3,800 kg |
| Maximum Gross Weight: | 30,480 kg | 30,480 kg |
| Minimum Net Weight: | 28,180 kg | 26,680 kg |
| | |
| Stacking | | |
| Stacking Height: | 8 High | 8 High |
| Stacking Test Load per Post: | 96,012 kg | 96,012 kg |
Packaging and transportation
| STEP1 | The factory determines the delivery time and leases the booking to
the shipping company. |
| STEP2 | Provide export clearance documents and related expenses. |
| STEP3 | The factory sealed the box and shipped it to the port three days in
advance. |
| STEP4 | The goods leave the port of shipment and are shipped to the port of
destination. |
| STEP5 | Received the shipping company's delivery notice and proceeded with
customs formalities in advance. |
| STEP6 | The goods orrive ot the port of destination and are picked up
according tothe bill of lading. |
Products and services
1. Export the spare parts list for customers to check after
arrival.
2. While providing product information to customers, we can also
modify the design according to the requirements of customers.
3. In the process of making products again and again, we should
constantly absorb the wrong experience in the past products,
summarize and improve them, so that the future products will be
more perfect and upgraded.
Why choose us
1. Factory direct sales
2. Support customized production services
3. Professional design team can provide housing design service
4. After sales service
5. With pictures or text, according to your ideas
